| Tank trailer specification | ||
|---|---|---|
| 1 | Cargo | Fuels and other corrosive liquids. |
| 2 | Overall dimension | 11800×2500×3500mm (L×W×H) (Approx., based on final design drawings.) |
| 3 | Curb weight | 9800kg (Approx., based on final design drawings.) |
| 4 | Fifth-wheel height | 1350mm (Generally within 1250 - 1450 mm; precise dimensions required) |
| 5 | Axle | 13T Brand TSV with ABS and automatic slack adjusters & 3 units. (BPW/Fuwa/L1 brands optional) |
| 6 | Tire | 12R22.5 & 12 units (Tubeless type). (Triangle/Doublecoin/Linglong/Chaoyang brands optional) |
| 7 | Rim | 9.00 & 12 units, high-strength iron. |
| 8 | Kingpin | 50# (2") or 90# (3.5"), standard bolt type & JOST brand |
| 9 | Landing gear | Capacity 28T, JOST brand, Model A300C (Fuwa brand optional) |
| 10 | Suspension | Mechanical suspension, leaf springs, 13mm×90mm, 10pcs (16mm×90mm, 10pcs, heavy-duty design optional) |
| Tank body specification | ||
| 11 | Tank shape | Square-round (Double D) and gooseneck design. |
| 12 | Tank capacity | 42,000 liters (valid volume) + 5% (ullage) |
| 13 | Tank material | Stainless steel 30408 (316L optional) |
| 14 | Tank design thickness |
End cover: 5mm
Tank body: 4mm
Baffle: 4mm |
| Main parts specification | ||
| 15 | Beam | Heavy-duty and extra durable T-type beam, high tensile Q355B |
| 16 | Compartment | 3 units,14,000L+14,000L+14,000L per compartment. |
| 17 | Manhole cover | Stainless steel & 3 units, factory standard. (Jialong brand with ADR certificate optional) |
| 18 | Bottom valve | 4” Stainless steel & 3 units, factory standard. (Jialong brand with ADR certificate optional) |
| 19 | Discharging valve | 4” Stainless steel ball-type valve & 3 units (API valve optional) |
| 20 | Discharging hose box | 6 meters & 2 units. |
| 21 | Discharging hose | Anti-static type, 5.7 meters & 2 units. |
| 22 | Handrail | 2 units on the top. |
| 23 | Walkway platform | Top with anti-slip punched design. |
| 24 | Ladder | 1 unit, on the rear or front. |
| 25 | Breather valve | Stainless steel & 3 units. |
| 26 | Spare wheel carrier | 2 units. |
| 27 | Mud guard plate | Integrated design plate, carbon steel. |
| 28 | Relay valve | WABCO brand |
| 29 | Reverse buzzer | 1 unit. |
| 30 | Electric system | 24V, 7-pin socket, national standard. |
| 31 | Lights | LED lights with protection. Side/rear/stop/indicator/parking/fog/reverse/clearance lights, etc. |
| 32 | Painting |
Primer layer: One coat of anti-corrosive paint.
Final coat: Two coats of finish paint.
Color: As per customer's requirements. |
| 33 | Delivery | Spray wax before departure and cover with tarpaulin for protection. |
| Other equipment | ||
|
1. Single tool box, maximum available size.
2. Single valve box, maximum available size.
3. Loading and unloading on left side.
4. Two sets of 8KG fire extinguishers with boxes.
5. One set of anti-static grounding strap.
6. All other necessary accessories. |
||
42CBM Stainless Steel Tank Semi-trailer| Factory Price – Sailingvehicle
⭐⭐⭐⭐⭐
Price:23,300 – 28,500 USD （Prices vary by configuration）
Get the best 42CBM stainless steel tank semi-trailer for chemical or food-grade transport. High corrosion resistance & superior safety features. Request a quote!
Brand: TSV-SAILING
Model: TSV201901-42
Type: Fuel Tank Semi-trailer
Origin: China
Payment Term: T/T
Delivery time: 15-25 days
Shipping: Bulk cargo ship/Ro-Ro ship/Container shipment / SKD / CKD / etc.
Trailer Highlights
Are you seeking to dramatically elevate your bulk liquid transport capabilities with unparalleled hygiene and durability? Investing in our top-of-the-line 42CBM Stainless Steel Tank Semi-trailer is the ultimate, highly efficient solution for your commercial B2B logistics fleet. Engineered precisely for demanding food-grade liquids and highly corrosive chemicals, this specialized heavy-duty transport equipment significantly reduces cross-contamination risks while simultaneously maximizing your daily payload efficiency and long-term profitability.
Advanced Engineering of Our 42CBM Stainless Steel Tank Semi-trailer
The core advantage of this exceptional transport vehicle lies in its premium material construction and intelligent structural engineering. The high-grade stainless steel body offers extraordinary corrosion resistance, ensuring the highest sanitation standards and effortless cleaning protocols. This guarantees a highly extended service life, making it the perfect asset for safely transporting delicate products like edible oils, milk, or specialized industrial chemicals.
Furthermore, the innovative gooseneck chassis design is a game-changer for highway stability. By substantially lowering the vehicle’s center of gravity, this specific structural enhancement guarantees remarkably safer transit, effectively minimizing dangerous rollover risks during high-speed, heavy-duty operations.
Robust Components and Uncompromised Fleet Safety
Operational safety and component reliability are our top priorities. We reinforce the tank top with a highly durable box-shaped coaming to enhance overall structural stability. During nighttime logistics operations, the strategically applied high-visibility reflective warning tape ensures your fleet remains safe and noticeable on the road. Learn more about international tank truck safety standards to understand how our industrial manufacturing consistently meets strict global compliance.
To guarantee continuous, uninterrupted performance under maximum payloads, the trailer rolls on world-renowned axle brands such as Fuwa and BPW. For highly reliable uncoupling, we equip the trailer with heavy-duty JOST landing gear (Model A300C), providing a massive 28T load capacity. Additionally, standardized electrical and pneumatic connectors ensure rapid and highly secure tractor integration.
By integrating this highly hygienic and incredibly durable equipment into your logistics operations, you will minimize maintenance downtime and drive sustainable B2B profitability. Ready to elevate your transport fleet’s performance? Contact us today to request a comprehensive quotation and precise technical specifications tailored to your business needs!
Product Overview
Reinforce your trailer's structural integrity with our robust box-shaped coaming on the tank top. This durable design significantly enhances payload stability, ensures maximum operational safety, and extends the lifespan of your valuable transport equipment.
2. Premium Stainless Steel Tank
Maximize hygiene with our premium stainless steel tanker. Delivering excellent corrosion resistance and effortless cleaning, it guarantees a long service life and is the absolute perfect solution for safely transporting delicate food-grade liquids.
3. Stable Gooseneck Design
Experience unparalleled highway stability with our innovative gooseneck chassis design. By substantially lowering the vehicle's overall center of gravity, it effectively minimizes rollover risks, ensuring remarkably safer and smoother heavy-duty liquid transport operations.
4. Reflective Warning Tape
Prioritize road safety with strategically applied, high-visibility reflective warning tape. This essential safety feature ensures your transport fleet remains highly visible to other drivers during harsh weather conditions and demanding nighttime logistics operations.
5. World-Class Axle Systems
Conquer challenging logistics routes with absolute confidence. We equip our robust trailers with internationally recognized axle brands like Fuwa and BPW, delivering extraordinary load-bearing capacity, minimal maintenance downtime, and exceptional operational longevity.
6. Versatile Discharge System
Accelerate your fluid transfer operations with our highly versatile discharge system. Select between precision-engineered API valves or durable ball valves to guarantee secure, exceptionally rapid, and perfectly leak-proof unloading tailored to your exact needs.
7. JOST Landing Gear
Guarantee uncompromised stability during uncoupled parking phases. We utilize heavy-duty JOST landing gear (Model A300C), boasting an impressive 28-ton load capacity to safely support your heavy payloads and prevent hazardous structural failures.
8. Standardized Electrical Connectors
Ensure seamless tractor integration with our premium electrical and pneumatic connectors. Strictly meeting national standards, these high-quality components guarantee a quick, stable, and incredibly safe connection, significantly reducing pre-trip preparation and maintenance time.
| Note: We will design drawings according to your requirements. |
 |
 |
 |
Screw Rust Prevention
During the pre-shipment packaging of the semi-trailer, anti-rust oil is applied to the bolts to prevent corrosion during transportation.01
Spray preservative
Built for the long haul! Every semi-trailer part is treated with premium anti-corrosion spray before leaving our factory, ensuring maximum rust protection and lasting durability.02
Wax Spray
Factory-fresh and fully protected! Our pre-delivery full-trailer wax spraying shields against corrosion and weather, guaranteeing a lasting shine and maximum durability from day one.03
Tarping
Flawless delivery guaranteed! Every trailer is fully tarped before leaving our factory, shielding your investment from dust and weather so it arrives in pristine condition.04
Preparing the tank trailer for sea freight
Ready for the global stage! Our expert packaging and secure vessel loading ensure your tank trailers cross the ocean safely, arriving in perfect condition anywhere in the world.05
GET YOUR FREE QUOTE
Please fill in the form with details, so that we can send you a quotation correctly.
Please understand that there is a 5-8 hour time difference between China and Africa. We will send you the latest quotation within 2 hours after starting work in Beijing time.
If you also want more detailed trailers' introduction brochures, drawings, pictures, videos and other details. Please describe the type of semi-trailer you want in the form below, and leave your usual contact information, Email or Whastapp.
Our Advantages
Robust Suspension for Harsh Road Conditions
Designed specifically for the challenging road conditions often found in Africa, Southeast Asia, and South America, our trailer chassis is reinforced with heavy-duty mechanical suspension and widened leaf springs. Customers can also opt for air suspension systems for sensitive cargo. Paired with 12R22.5 or 315/80R22.5 wear-resistant tires, the trailer maintains excellent stability, reduces tire wear, and extends the overall lifespan of the vehicle even when navigating unpaved or mountainous roads.
Shipping and Delivery Solutions
We provide cost-effective and secure shipping solutions for global buyers. For a standard trailer, we typically recommend RORO (Roll-on/Roll-off) ships or bulk cargo ships. To provide the highest level of protection, we thoroughly spray the entire exterior with a protective wax coating and securely cover the vehicle with heavy-duty tarpaulins before it leaves the factory. This double-layered protection prevents seawater rust and weather damage during the voyage, ensuring the trailer arrives at your port in pristine condition.
Reliable After-Sales Support and Spare Parts
As a direct manufacturer, we don’t just sell trailers; we build long-term business partnerships. Every trailer comes with a comprehensive one-year warranty covering the main chassis and tank body. We understand that vehicle downtime costs you money, which is why we maintain a complete inventory of OEM spare parts, including API valves, brake pads, and suspension components. Our dedicated technical support team is always available to provide maintenance guidance and remote troubleshooting, ensuring your fleet remains safely on the road.
Why Choose Sailingvehicle for Your Transport Fleet?
With years of experience in heavy-duty commercial vehicle manufacturing, Sailingvehicle provides factory-direct pricing without compromising on quality. We have successfully exported thousands of trailers to international markets, earning a solid reputation for durability and excellence. Whether you need a standard trailer or a fully customized hauling solution, our engineering team is ready to deliver unmatched value to your business.
