| Container tank specification | |||
|---|---|---|---|
| 1 | Cargo | Gasoline, diesel, kerosene, and other petroleum oils | |
| 2 | Dimensions | Outer |
6058×2438×2591mm (L×W×H)
(Based on final design drawings.) |
| Centre distance between twistlocks |
5985×2259 mm (L×W)
(Based on final design drawings.) |
||
| 3 | Curb weight |
5500kg
(Approx., based on final design drawings.) |
|
| Tank body specification | |||
| 4 | Tank shape | Round cylindrical. | |
| 5 | Tank capacity | 26,000 liters | |
| 6 | Tank material | AL5182 | |
| 7 | Tank design thickness | End cover | 4.5mm |
| Tank body | 4mm | ||
| Baffle | 4mm | ||
| 8 | Insulation material | Rock wool, with multilayer insulation felt. | |
| 9 | Insulation material thickness |
50 mm
(30mm,80mm,100mm, or other thickness options are available). |
|
| 10 | Insulation cover plate | Color-coated plate | |
| 11 | Insulation cover plate thickness | 0.5mm, National standard. | |
| 12 | Heating system | Oven, steam, or burner. | |
| Main parts specification | |||
| 13 | Compartment | Single | |
| 14 | Manhole cover | Aluminum alloy & 2 units, 3-top and 6-bottom bolted configuration | |
| 15 | Bottom valve | Bottom & discharge integrated combination valve & 1 unit | |
| 16 | Discharging valve | ||
| 17 | Discharging hose box | 6 meters & 2 units. | |
| 18 | Discharging hose | Anti-static type, 5.7 meters & 2 units. | |
| 19 | Handrail | 2 units on the top, Stainless steel material | |
| 20 | Walkway platform | On the top with anti-slip punched design, aluminum alloy material | |
| 21 | Ladder | 1 unit, on the rear | |
| 22 | Breather valve | Aluminum alloy & 2 units. | |
| 23 | Painting | Primer layer | One coat of anti-corrosive paint. |
| Final coat | Two coats of finish paint. | ||
| Color | As per customer's requirements. | ||
| 24 | Delivery | Spray wax before departure and cover with tarpaulin for protection. | |
20FT Insulated Aluminum Alloy ISO Container Tanker| Factory Price – Sailingvehicle
⭐⭐⭐⭐⭐
Price: 17,400 – 20,400 USD（Prices vary by configuration）
Maximize thermal efficiency with our 20FT Insulated Aluminum Alloy ISO Container Tanker. Built for safe, lightweight bulk liquid transport. Contact us today!
Brand: TSV-SAILING
Model: TSV201701-20
Type: Container Frame Tank Semi-trailer Insulation Tank Semi-trailer
Origin: China
Payment Term: T/T
Delivery time: 15-25 days
Shipping: Bulk cargo ship/Ro-Ro ship/Container shipment / SKD / CKD / etc.
Trailer Highlights
Upgrading your heavy transport fleet with a high-performance 20FT Insulated Aluminum Alloy ISO Container Tanker is absolutely essential for businesses handling temperature-sensitive bulk liquids. Engineered for optimal thermal retention and exceptional lightweight durability, this specialized logistics equipment allows you to securely haul edible oils, delicate liquid chemicals, or specialized industrial fluids across demanding global supply chains. By utilizing advanced aluminum construction to minimize the overall tare weight, commercial operators can significantly increase their maximum legal payload capacity, instantly maximizing daily profitability and long-term transport efficiency.
Advanced Engineering of the 20FT Insulated Aluminum Alloy ISO Container Tanker
When handling critical commercial fluids, maintaining exact product temperatures during transit is paramount to preventing spoilage or solidification. Our premium tanker features a superior insulated shell seamlessly combined with an advanced integrated steam heating channel. This dual-action thermal design ensures extreme environmental weather conditions never compromise your cargo’s vital viscosity. The naturally lightweight nature of the aluminum alloy provides exceptional anti-corrosion properties while drastically reducing truck fuel consumption over long hauls. Furthermore, the robust intermodal freight transport framework of this 20FT Insulated Aluminum Alloy ISO Container Tanker ensures strict compliance with standardized international shipping dimensions, enabling effortless modular transfers between heavy-duty commercial trucks, railcars, and maritime cargo vessels.
Optimized for Operational Safety and Efficiency
Every industrial unit is meticulously equipped with a heavy-duty stainless steel discharge valve and an automated pressure relief safety vent. These core components guarantee fast, leak-proof unloading operations and consistently prevent hazardous internal pressure buildup.
Maximize Your Intermodal Transport Operations
Choosing our commercial-grade liquid transport equipment means actively investing in unparalleled logistical reliability and extended mechanical lifespan. The structurally reinforced ISO container frame guarantees secure modular stacking at busy ports, while the slip-resistant folding aluminum walkway strictly prioritizes operator safety during critical routine overhead inspections. By integrating these specific advanced engineering features, logistics companies can significantly minimize expensive mechanical downtime and accelerate bulk product turnaround speeds at demanding terminal destinations.
If your enterprise is prepared to rapidly elevate its bulk fluid logistics with a reliable 20FT Insulated Aluminum Alloy ISO Container Tanker, our expert engineering team is readily available to assist. Contact us today to request a highly customized quotation and comprehensive technical blueprints tailored specifically for your next major fleet upgrade.
Product Overview
1. Premium Insulation Layer
Our premium insulation layer critically minimizes heat loss during transit. This advanced thermal protection significantly reduces destination heating times, drastically lowering your operational energy costs and accelerating overall unloading efficiency.
2. 316L Stainless Steel Shell
Manufactured from premium 316L stainless steel, this container strictly meets global food-grade standards. This high-quality material guarantees absolute oil purity, exceptional corrosion resistance, and ensures maximum regulatory compliance.3. Optimized 25m³ Capacity
The precisely optimized 25m³ capacity perfectly matches standard palm oil density. This intelligent volumetric design securely maximizes your legal transport payloads, significantly boosting economic returns for every B2B logistics shipment.
4. FEA-Optimized Frameworks
Structurally advanced, FEA-optimized frameworks safely withstand frequent, heavy-duty port lifting operations. This robust engineering completely eliminates dangerous metal fatigue risks, exceptionally extending your industrial asset's operational lifespan under demanding conditions.
5. Mirror-Polished Interiors
High-grade mirror-polished interiors effectively prevent sticky, viscous oil adhesion. This premium surface treatment drastically shortens mandatory cleaning times, slashes maintenance labor costs, and completely eliminates dangerous inter-batch cross-contamination risks.
6. Heated Bottom Discharge Valves
Specialized heated bottom discharge valves completely prevent thick, high-viscosity palm oil from clogging your pipelines. This innovative thermal feature ensures consistently smooth fluid transfer, radically improving your terminal unloading efficiency.
7. Steam Heating Channels
Highly efficient integrated steam heating channels rapidly melt solidified palm oil upon destination arrival. This powerful thermal management system ensures smooth discharge processes, significantly minimizing costly logistics downtime.
8. Integrated Thermometers & Ports
Precision thermometers and secure closed ports allow safe, real-time cargo monitoring and sampling. Operators can reliably verify temperatures without opening manholes, perfectly preserving thermal efficiency and strict cargo integrity.
| Note: We will design drawings according to your requirements. |
 |
 |
 |
Screw Rust Prevention
During the pre-shipment packaging of the semi-trailer, anti-rust oil is applied to the bolts to prevent corrosion during transportation.01
Spray preservative
Built for the long haul! Every semi-trailer part is treated with premium anti-corrosion spray before leaving our factory, ensuring maximum rust protection and lasting durability.02
Wax Spray
Factory-fresh and fully protected! Our pre-delivery full-trailer wax spraying shields against corrosion and weather, guaranteeing a lasting shine and maximum durability from day one.03
Tarping
Flawless delivery guaranteed! Every trailer is fully tarped before leaving our factory, shielding your investment from dust and weather so it arrives in pristine condition.04
Preparing the tank trailer for sea freight
Ready for the global stage! Our expert packaging and secure vessel loading ensure your tank trailers cross the ocean safely, arriving in perfect condition anywhere in the world.05
GET YOUR FREE QUOTE
Please fill in the form with details, so that we can send you a quotation correctly.
Please understand that there is a 5-8 hour time difference between China and Africa. We will send you the latest quotation within 2 hours after starting work in Beijing time.
If you also want more detailed trailers' introduction brochures, drawings, pictures, videos and other details. Please describe the type of semi-trailer you want in the form below, and leave your usual contact information, Email or Whastapp.
Our Advantages
Robust Suspension for Harsh Road Conditions
Designed specifically for the challenging road conditions often found in Africa, Southeast Asia, and South America, our trailer chassis is reinforced with heavy-duty mechanical suspension and widened leaf springs. Customers can also opt for air suspension systems for sensitive cargo. Paired with 12R22.5 or 315/80R22.5 wear-resistant tires, the trailer maintains excellent stability, reduces tire wear, and extends the overall lifespan of the vehicle even when navigating unpaved or mountainous roads.
Shipping and Delivery Solutions
We provide cost-effective and secure shipping solutions for global buyers. For a standard trailer, we typically recommend RORO (Roll-on/Roll-off) ships or bulk cargo ships. To provide the highest level of protection, we thoroughly spray the entire exterior with a protective wax coating and securely cover the vehicle with heavy-duty tarpaulins before it leaves the factory. This double-layered protection prevents seawater rust and weather damage during the voyage, ensuring the trailer arrives at your port in pristine condition.
Reliable After-Sales Support and Spare Parts
As a direct manufacturer, we don’t just sell trailers; we build long-term business partnerships. Every trailer comes with a comprehensive one-year warranty covering the main chassis and tank body. We understand that vehicle downtime costs you money, which is why we maintain a complete inventory of OEM spare parts, including API valves, brake pads, and suspension components. Our dedicated technical support team is always available to provide maintenance guidance and remote troubleshooting, ensuring your fleet remains safely on the road.
Why Choose Sailingvehicle for Your Transport Fleet?
With years of experience in heavy-duty commercial vehicle manufacturing, Sailingvehicle provides factory-direct pricing without compromising on quality. We have successfully exported thousands of trailers to international markets, earning a solid reputation for durability and excellence. Whether you need a standard trailer or a fully customized hauling solution, our engineering team is ready to deliver unmatched value to your business.
